YATO

JIG SAW 750W

SKU: 100524-0001
(0)
€78,68 inc. VAT
Coming soon
On order

If you like the product, please help us by sharing on social media. Many thanks!

Got questions, ask an expert!

Email +36 70 719 8323

This 750 W jig saw is designed for professional cutting tasks in wood and soft metals. It suits workshops, maintenance teams, and trade users who need variable speed, 45° cutting angle adjustment, 4-stage pendulum action, and tool-free T-blade replacement.

Key Features

  • 750 W Motor: designed for cutting tasks in wood and soft metals.
  • Variable Speed: electronic rotation adjustment from 600–2800 min⁻¹ for adapting cutting speed to the material.
  • Cutting Capacity: cuts up to 150 mm in wood and 10 mm in soft metal.
  • Adjustable Cutting Angle: cutting angle regulation up to 45° for bevel cuts.
  • 4-Stage Pendulum Function: pendulum function with 4 settings for different cutting requirements.
  • Tool-Free Blade Replacement: supports T-type blades with toolless blade replacement.
  • Dust Extraction Connection: supplied with a dust extraction adapter for cleaner operation when connected to suitable extraction equipment.

Technical Specifications

Parameter Value
Brand YATO
Product Type Jig saw
SKU 100524-0001
Power 750 W
Voltage 230–240 V a.c.
Frequency 50 Hz
Rotation Speed 600–2800 min⁻¹
Saw Blade Stroke 28 mm
Max. Cutting Thickness In Wood 150 mm
Max. Cutting Thickness In Soft Metal 10 mm
Cutting Angle Regulation 45°
Functions Pendulum, 4-stage
Blade Type T-type
Electronic Rotation Adjustment Yes
Toolless Blade Replacement Yes
Cable Length 3 m
Electric Insulation Class II
Protection Grade IP20
Acoustic Pressure 89.0 ± 3.0 dB(A)
Acoustic Power 100.0 ± 3.0 dB(A)
Vibrations 8.87 ± 1.5 / 5.51 ± 1.5 m/s²
Product Weight 3.15 kg
Shipping Weight 3.9 kg
Dimensions 52 × 4.5 × 3.5 cm
Volume 7.861
Unit Of Measure PCE

Package Contents

  • 1 × jig saw
  • 1 × guide
  • 1 × saw blade guard
  • 1 × saw blade
  • 1 × dust extraction connection
