UNI-T Digital Multimeter, 1000 V DC/750 V AC, 20 A AC/DC, 1000 μF, 20 kHz, -40-1000 °C – UT58C

SKU: 003093
(0)
14.677 Ft inc. VAT
In stock · 3 items available
Ships Within 3-5 Working Days
Variants

If you like the product, please help us by sharing on social media. Many thanks!

Got questions, ask an expert!

Email +36 70 719 8323

The UNI-T UT58C is a general-purpose manual-ranging digital multimeter for electrical testing, equipment maintenance and circuit troubleshooting. Its large display, broad measurement capabilities and input connection indication make it suitable for professional MRO, workshop and field applications.

Key Features

  • Measures AC/DC voltage, AC/DC current and resistance
  • Capacitance measurement up to 100 µF and frequency measurement up to 20 kHz
  • Temperature measurement range from −40°C to 1000°C
  • Large 1999-count display with data hold and test lead connection indication
  • Diode, continuity and transistor testing with automatic power-off

Product Specifications

Parameter Range / Specification Basic Accuracy
DC Voltage 200 mV / 2 V / 20 V / 200 V / 1000 V ±(0.5% + 1)
AC Voltage 2 V / 20 V / 200 V / 750 V ±(0.8% + 3)
DC Current 2 mA / 200 mA / 20 A ±(0.8% + 1)
AC Current 2 mA / 200 mA / 20 A ±(1% + 3)
Resistance 200 Ω / 2 kΩ / 20 kΩ / 2 MΩ / 20 MΩ ±(0.8% + 1)
Capacitance 2 nF / 200 nF / 100 µF ±(4% + 3)
Frequency 2 kHz / 20 kHz ±(1.5% + 5)
Temperature −40°C to 1000°C ±(1% + 3)
Display 1999 counts, 60 × 54 mm LCD
Ranging Mode Manual ranging
Response Type Average responding
Additional Functions Data hold, diode test, continuity buzzer, transistor test, automatic power-off, low-battery indication and input connection indication
Input Impedance ≥10 MΩ
Power Supply 1 × 9 V battery (6F22)
Product Dimensions 179 × 88 × 39 mm
Product Weight Approximately 350 g, including protective holster

Applications

  • Electrical installation, inspection and fault diagnosis
  • Industrial machinery and production equipment maintenance
  • Electronic circuit and component testing
  • HVAC, temperature measurement and general MRO work

Included Components

  • UNI-T UT58C digital multimeter
  • Test leads
  • Point-contact temperature probe
  • Multi-purpose test socket
  • Protective holster
  • 9 V battery
  • User manual and warranty documentation
